TECHNICAL SPECIFICATIONS |
|||
|
FILTER CLASS |
EN 1822 |
H13 |
H14 |
|
ISO 29463 |
ISO 35 H |
ISO 45 H |
|
|
SEALING COMPOUND |
Two component polyurethane |
||
|
FRAME TYPE |
MDF |
||
|
FACEGUARD |
Available on request |
||
|
GASKET |
EPDM flat, continuous EPDM flat, PU foam |
||
|
MEDIA |
High quality glass fibre |
||
|
SEPARATOR |
Hot melt technology |
||
|
FIRE CLASS |
K2 / F2 (standard applications) |
||
|
MAX OPERATING TEMPERATURE |
75°C |
||
|
APPLICATION |
|||
|
Cleanrooms |
|||
|
Operating theatres |
|||
|
Pharmaceutical and healthcare environments |
|
Product Code |
Classification |
Dimensions (WxHxD) |
Pleat Height |
Flow Rate |
Filter surface |
Initial Pressure Drop |
Max. Final Pressure Drop |
Efficiency @ MPPS |
Weight |
|
|
En1822 |
ISO 29463 |
mm |
mm |
m³/h |
m² |
Pa |
Pa |
% |
Kg |
|
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
305x305x149 |
50 |
150 |
2,25 |
100 |
600 |
99,95 |
3,5 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
305x610x149 |
50 |
300 |
4,5 |
100 |
600 |
99,95 |
5,5 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
457x457x149 |
50 |
340 |
5,1 |
100 |
600 |
99,95 |
4,2 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
457x610x149 |
50 |
450 |
6,7 |
100 |
600 |
99,95 |
5,9 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
535x535x149 |
50 |
460 |
6,9 |
100 |
600 |
99,95 |
6,2 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
575x575x149 |
50 |
535 |
8 |
100 |
600 |
99,95 |
6,5 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
610x610x149 |
50 |
600 |
9 |
100 |
600 |
99,95 |
7 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
610x762x149 |
50 |
750 |
11,3 |
100 |
600 |
99,95 |
7,8 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
610x915x149 |
50 |
900 |
13,5 |
100 |
600 |
99,95 |
8,8 |
|
MGH-13-M-FNPI-50 |
H13 |
ISO 35 H |
610x1220x149 |
50 |
1200 |
18 |
100 |
600 |
99,95 |
13,4 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
305x305x149 |
75 |
230 |
3,4 |
100 |
600 |
99,95 |
3,9 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
305x610x149 |
75 |
450 |
6,8 |
100 |
600 |
99,95 |
6,1 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
457x457x149 |
75 |
520 |
7,8 |
100 |
600 |
99,95 |
4,6 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
457x610x149 |
75 |
670 |
10 |
100 |
600 |
99,95 |
6,5 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
535x535x149 |
75 |
690 |
10,3 |
100 |
600 |
99,95 |
6,8 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
575x575x149 |
75 |
800 |
12 |
100 |
600 |
99,95 |
7,2 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
610x610x149 |
75 |
900 |
13,5 |
100 |
600 |
99,95 |
7,7 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
610x762x149 |
75 |
1150 |
17,3 |
100 |
600 |
99,95 |
8,6 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
610x915x149 |
75 |
1350 |
20,3 |
100 |
600 |
99,95 |
9,7 |
|
MGH-13-M-FNPI-75 |
H13 |
ISO 35 H |
610x1220x149 |
75 |
1800 |
27 |
100 |
600 |
99,95 |
14,7 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
305x305x149 |
100 |
300 |
4,5 |
100 |
600 |
99,95 |
4,3 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
305x610x149 |
100 |
600 |
9 |
100 |
600 |
99,95 |
6,7 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
457x457x149 |
100 |
680 |
10,2 |
100 |
600 |
99,95 |
5,1 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
457x610x149 |
100 |
890 |
13,4 |
100 |
600 |
99,95 |
7,2 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
535x535x149 |
100 |
920 |
13,8 |
100 |
600 |
99,95 |
7,5 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
575x575x149 |
100 |
1050 |
16 |
100 |
600 |
99,95 |
7,9 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
610x610x149 |
100 |
1200 |
18 |
100 |
600 |
99,95 |
8,5 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
610x762x149 |
100 |
1500 |
22,6 |
100 |
600 |
99,95 |
9,5 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
610x915x149 |
100 |
1800 |
27 |
100 |
600 |
99,95 |
10,7 |
|
MGH-13-M-FNPI-100 |
H13 |
ISO 35 H |
610x1220x149 |
100 |
2400 |
36 |
100 |
600 |
99,95 |
16,2 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
305x305x149 |
50 |
150 |
2,25 |
125 |
600 |
99,995 |
3,5 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
305x610x149 |
50 |
300 |
4,5 |
125 |
600 |
99,995 |
5,5 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
457x457x149 |
50 |
340 |
5,1 |
125 |
600 |
99,995 |
4,2 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
457x610x149 |
50 |
450 |
6,7 |
125 |
600 |
99,995 |
5,9 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
535x535x149 |
50 |
460 |
6,9 |
125 |
600 |
99,995 |
6,2 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
575x575x149 |
50 |
535 |
8 |
125 |
600 |
99,995 |
6,5 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
610x610x149 |
50 |
600 |
9 |
125 |
600 |
99,995 |
7 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
610x762x149 |
50 |
750 |
11,3 |
125 |
600 |
99,995 |
7,8 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
610x915x149 |
50 |
900 |
13,5 |
125 |
600 |
99,995 |
8,8 |
|
MGH-14-M-FNPI-50 |
H14 |
ISO 45 H |
610x1220x149 |
50 |
1200 |
18 |
125 |
600 |
99,995 |
13,4 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
305x305x149 |
75 |
230 |
3,4 |
125 |
600 |
99,995 |
3,9 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
305x610x149 |
75 |
450 |
6,8 |
125 |
600 |
99,995 |
6,1 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
457x457x149 |
75 |
520 |
7,8 |
125 |
600 |
99,995 |
4,6 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
457x610x149 |
75 |
670 |
10 |
125 |
600 |
99,995 |
6,5 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
535x535x149 |
75 |
690 |
10,3 |
125 |
600 |
99,995 |
6,8 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
575x575x149 |
75 |
800 |
12 |
125 |
600 |
99,995 |
7,2 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
610x610x149 |
75 |
900 |
13,5 |
125 |
600 |
99,995 |
7,7 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
610x762x149 |
75 |
1150 |
17 |
125 |
600 |
99,995 |
8,6 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
610x915x149 |
75 |
1350 |
20,3 |
125 |
600 |
99,995 |
9,7 |
|
MGH-14-M-FNPI-75 |
H14 |
ISO 45 H |
610x1220x149 |
75 |
1800 |
27 |
125 |
600 |
99,995 |
14,7 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
305x305x149 |
100 |
300 |
4,5 |
125 |
600 |
99,995 |
4,3 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
305x610x149 |
100 |
600 |
9 |
125 |
600 |
99,995 |
6,7 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
457x457x149 |
100 |
680 |
10,2 |
125 |
600 |
99,995 |
5,1 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
457x610x149 |
100 |
890 |
13,4 |
125 |
600 |
99,995 |
7,2 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
535x535x149 |
100 |
920 |
13,8 |
125 |
600 |
99,995 |
7,5 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
575x575x149 |
100 |
1050 |
16 |
125 |
600 |
99,995 |
7,9 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
610x610x149 |
100 |
1200 |
18 |
125 |
600 |
99,995 |
8,5 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
610x762x149 |
100 |
1500 |
22,6 |
125 |
600 |
99,995 |
9,5 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
610x915x149 |
100 |
1800 |
27 |
125 |
600 |
99,995 |
10,7 |
|
MGH-14-M-FNPI-100 |
H14 |
ISO 45 H |
610x1220x149 |
100 |
2400 |
36 |
125 |
600 |
99,995 |
16,2 |
