TECHNICAL SPECIFICATIONS |
|
|
FILTER CLASS |
F7 |
|
MEDIA |
Activated carbon granules between synthetic layers |
|
FRAME TYPE |
Plastic |
|
APPLICATION |
Prefilter for HVAC, odour removal |
|
MAX OPERATING TEMPERATURE |
80°C |
|
Product Code |
Class |
Dimensions (WxHxD) |
Air flow |
Filter surface |
Initial Pressure Drop |
Max. Final Pressure Drop |
Weight |
|
|
mm |
m³/h |
m² |
Pa |
Pa |
Kg |
|||
|
MGK-AC7-P-4V-FNW-25 |
F7 |
592x287x292 |
1700 |
5 |
70 |
600 |
4 |
|
|
MGK-AC7-P-4V-FNW-25 |
F7 |
592x490x292 |
2800 |
7 |
70 |
600 |
6 |
|
|
MGK-AC7-P-4V-FNW-25 |
F7 |
592x592x292 |
3400 |
9 |
70 |
600 |
6,7 |
|
