TECHNICAL SPECIFICATIONS |
||
|
FILTER CLASS |
EN 779-2012 |
F9 |
|
ISO 16890 |
ePM1 80% |
|
|
MEDIA |
Synthetic |
|
|
FRAME TYPE |
Galvanized Steel, Plastic |
|
|
MAX OPERATING TEMPERATURE |
75°C |
|
|
HEADER |
20-25 mm |
|
|
APPLICATION |
||
|
Medium to high efficiency filtration |
||
|
Pre-filtration for hepa filters |
|
Product Code |
Class |
Dimensions |
Pocket |
Air flow |
Filter surface |
Initial Pressure Drop |
Max. Final Pressure Drop |
Weight |
||
|
EN 779 |
ISO 16890 |
mm |
m³/h |
m² |
Pa |
Pa |
Kg |
|||
|
MGB-9-SG-25-4 |
F9 |
ePM1 80% |
287x592x360 |
4 |
1700 |
1,8 |
150 |
450 |
1,1 |
|
|
MGB-9-SG-25-6 |
F9 |
ePM1 80% |
490x592x360 |
6 |
2800 |
2,8 |
150 |
450 |
1,5 |
|
|
MGB-9-SG-25-8 |
F9 |
ePM1 80% |
592x592x360 |
8 |
3400 |
3,7 |
150 |
450 |
2 |
|
|
MGB-9-SG-25-4 |
F9 |
ePM1 80% |
287x592x535 |
4 |
1700 |
2,6 |
130 |
450 |
1,2 |
|
|
MGB-9-SG-25-6 |
F9 |
ePM1 80% |
490x592x535 |
6 |
2800 |
3,9 |
130 |
450 |
1,8 |
|
|
MGB-9-SG-25-8 |
F9 |
ePM1 80% |
592x592x535 |
8 |
3400 |
5,2 |
130 |
450 |
2,4 |
|
|
MGB-9-SG-25-4 |
F9 |
ePM1 80% |
287x592x600 |
4 |
1700 |
2,9 |
115 |
450 |
1,2 |
|
|
MGB-9-SG-25-6 |
F9 |
ePM1 80% |
490x592x600 |
6 |
2800 |
4,4 |
115 |
450 |
1,9 |
|
|
MGB-9-SG-25-8 |
F9 |
ePM1 80% |
592x592x600 |
8 |
3400 |
5,8 |
115 |
450 |
2,6 |
|
