TECHNICAL SPECIFICATIONS |
|||
|
FILTER CLASS |
EN 1822 |
H13 |
H14 |
|
ISO 29463 |
ISO 35 H |
ISO 45 H |
|
|
SEALING COMPOUND |
Two component polyurethane |
||
|
FRAME TYPE |
Galvanized steel,Aluminum steel, stainless steel |
||
|
GASKET |
EPDM flat, EPDM flat continous and PU foam |
||
|
MEDIA |
High quality glass fibre |
||
|
SEPARATOR |
Hot melt |
||
|
FIRE CLASS |
K2/F2 for Normal temp. |
||
|
MAX OPERATING TEMPERATURE |
75°C |
||
|
APPLICATION |
|||
|
High-efficiency HVAC systems as final filtration stage |
|||
|
Pharmaceutical and biotechnology production facilities |
|||
|
Hospitals, operating rooms |
|
Product Code |
Classification |
Dimensions (WxHxD) |
Flow Rate |
Filtration Area |
Initial Pressure Drop |
Max. Final Pressure Drop |
Efficiency @ MPPS |
Weight |
|
|
En1822 |
ISO 29463 |
mm |
m³/h |
m² |
Pa |
Pa |
% |
Kg |
|
|
MGHC-13-GV-FNPI-8 |
H13 |
ISO 35 H |
305x305x292 |
750 |
7 |
250 |
600 |
99,95 |
6 |
|
MGHC-13-GV-FNPI-15 |
H13 |
ISO 35 H |
305x610x292 |
1500 |
14 |
250 |
600 |
99,95 |
10 |
|
MGHC-13-GV-FNPI-23 |
H13 |
ISO 35 H |
457x610x292 |
2250 |
20,1 |
250 |
600 |
99,95 |
14,5 |
|
MGHC-13-GV-FNPI-30 |
H13 |
ISO 35 H |
610x610x292 |
3000 |
28 |
250 |
600 |
99,95 |
18 |
|
MGHC-13-GV-FNPI-38 |
H13 |
ISO 35 H |
610x762x292 |
3750 |
35 |
250 |
600 |
99,95 |
20 |
|
MGHC-14-GV-FNPI-8 |
H14 |
ISO 45 H |
305x305x292 |
750 |
7 |
280 |
600 |
99,995 |
6 |
|
MGHC-14-GV-FNPI-15 |
H14 |
ISO 45 H |
305x610x292 |
1500 |
14 |
280 |
600 |
99,995 |
10 |
|
MGHC-14-GV-FNPI-23 |
H14 |
ISO 45 H |
457x610x292 |
2250 |
20,1 |
280 |
600 |
99,995 |
14,5 |
|
MGHC-14-GV-FNPI-30 |
H14 |
ISO 45 H |
610x610x292 |
3000 |
28 |
280 |
600 |
99,995 |
18 |
|
MGHC-13-GV-FNPI-38 |
H14 |
ISO 45 H |
610x762x292 |
3750 |
35 |
280 |
600 |
99,995 |
20 |
